제품 상세 정보:
|
| 재료: | N08810 1.4958 B829 Incoloy 800H 스테인레스 스틸 이음매 없는 튜브/파이프 | 기술: | 어닐링된 산세 |
|---|---|---|---|
| 두께: | 1mm-50mm | 인증: | SGS, ISO, BV |
| 지름: | 6-630mm | 용법: | 관 수송, 석유 / 가스 시추, 기계 산업, 화학 산업, 건설 & 장식 |
| 표면 처리 :: | Annealed&는 소금물에 절였습니다 | 패키지: | 번들 또는 항해에 적합한 나무 상자에서 |
| 강조하다: | UNS N08810 nickel alloy pipe,Incoloy 800H seamless tube,Sch80 nickel alloy steel pipe |
||
N08810 1.4958 B829 Incoloy 800H Tube
Equivalent designations
UNS N08810
DIN W. Nr. 1.4958
Form ASTM
Rod and bar B 408
Plate, sheet and strip A 240, A 480, B 409, B 906
Seamless pipe and tube B 407, B 829
Welded pipe B 514, B 775
Welded tube B 515, B 751
Welding fitting B 366
Forging B 564
Part 2 . Chemical composition
| % | Fe | Ni | Cr | C | Mn | Si | S | Cu | Al | Ti |
| min | 39.5 | 30.0 | 19.0 | 0.05 | 0.15 | 0.15 | ||||
| max | 35.0 | 23.0 | 0.10 | 1.50 | 1.00 | 0.015 | 0.75 | 0.60 | 0.60 |
Physical properties
| Density | 7.94 g/cm3 |
| Melting range | 1357-1385ºC |
Features
Incoloy 800H has a restricted carbon content range of 0.05 to 0.10%, which is in the upper portion of that of Incoloy 800, and is annealed at 1149 to 1177ºC (Incoloy 800 is annealed at 983 to 1038ºC). These differences impart it to have higher stress rupture and creep properties than Incoloy 800.
Applications: Chemical and petrochemical process piping, high temperature heat exchangers, furnace components, carburizing equipment, heating-element sheathing, and nuclear power steam superheating tubing.
| Product Name | N08810 1.4958 B829 Incoloy 800h Stainless Steel Pipes / Tube |
| Other Material Grade | 202 304 304L 309S 310S 316L 317L 321 347 904L 2205 2507 .etc |
| Standard | ASTM,AISI, ASME ,SUS,JIS,EN,DIN,BS,GB .etc |
| Certification | ISO,SGS, BV |
| Brand | JISCO, LISCO, TISCO ,BAO STEEL POSCO/ ZPSS .etc |
|
SIZE
|
OD : 6-630 mm
|
| Wall Thickness : 1-50mm | |
|
Length: 6m or as your requirement
|
|
| Ends |
1) Plain 2) Beveled 3) Thread with Coupling or cap
|
| End protector |
1) Plastic pipe cap 2) Iron protector
|
| Surface Treatment |
1) Bared 2) Black Painted (varnish coating) 3) Galvanized 4) With Oiled 5) 3 PE, FBE, corrosion resistant coating
|
| Technique |
Electronic Resistance Welded (ERW ) Electronic Fusion Welded (EFW) Double Submerged Arc Welded (DSAW)
|
| Payment terms | L/C TT |
| Package | Standard export packing or as per customer’s request. |
| Deliver time | 5-7 days according to quantity |
Part 3 . Products List
Material/Grade : 304 321 316 316L 310S 309S 202 201 430 409L 444 410s 904L 2205 2507 Incoloy 800 800H 800HT 825 Inconel 600 625 718 Monel 400 Hastelloy C-276.etc
Part 4 . Packing and Shipping
Standard export packing or as per customer’s request .
Part 5 . Company Information---The Reason Why You Will Choose Us
Part 6 . Our Service
