제품 상세 정보:
|
| 제품: | 스틸 플레이트 | 등급: | 45#/1045/S45C |
|---|---|---|---|
| 두께 범위: | 1-20mm | 너비: | 1000-2500mm 또는 요청 |
| 길이: | 요청으로 사용자 정의 길이 | 서비스: | 절단 |
| 상표: | HBSC | 다른 등급: | 40CR 42CRMO Q355 |
Detail informations of our 1045 Steel Plate
|
Product Name
|
1045 Steel Plate |
|
Width
|
2200mm or custom as request
|
|
Length
|
custom as request |
| Thickness | 10 - 200mm |
|
Service
|
Cutting plate into any size as request |
|
Other Grade
|
1035 1040 1055 1060 1065 1070 1016 1037 1039 1046 1053 1566 1572 Grade 50 Grade 55 Grade 60 Grade 65 Grade 80 S35C S40C S50C S55C S58C SWRH67B SWRH72A SWRH77A 40 1040 65 1065 SWRCH22K C22E S550QL 1.8925 1.0114 1.0425 40Cr 5140
|
|
Application
|
Widely used in construction machinery, mining machinery, coal mining machinery, environmental protection machinery, metallurgical
machinery and other parts.Excavator, loader, bulldozer bucket plate, blade plate, side blade plate, blade.Crusher liner, blade |
|
MOQ
|
500 kgs |
|
Shipment time
|
5 - 7 days for mateials in stock |
AISI 1045 steel is characterized by good weldability, good machinability, and high strength and impact properties in either the normalized or hot-rolled condition.
AISI 1045 steel has a low through-hardening capability with only sections of around 60 mm in size being recommended as suitable for tempering and through-hardening. However, it can be efficiently flame- or induction-hardened in the normalized or hot rolled condition to obtain surface hardnesses in the range of Rc 54 - Rc 60 based on factors such as section size, type of set up, quenching medium used etc.
AISI 1045 steel lacks suitable alloying elements and hence does not respond to the nitriding process.
Chemical composition of AISI 1045
| C | FE | MN | P | S |
|---|---|---|---|---|
| 0.420 - 0.50% | 98.51 - 98.98% | 0.60 - 0.90% | ≤ 0.040% | ≤ 0.050% |
Mechanical Properties
| Mechanical Properties | Metric | Imperial |
|---|---|---|
| Hardness, Brinell | 163 | 163 |
| Hardness, Knoop (Converted from Brinell hardness) | 184 | 184 |
| Hardness, Rockwell B (Converted from Brinell hardness) | 84 | 84 |
| Hardness, Vickers (Converted from Brinell hardness) | 170 | 170 |
| Tensile Strength, Ultimate | 565 MPa | 81900 psi |
| Tensile Strength, Yield | 310 MPa | 45000 psi |
| Elongation at Break (in 50 mm) | 16.0 % | 16.0 % |
| Reduction of Area | 40.0 % | 40.0 % |
| Modulus of Elasticity (Typical for steel) | 200 GPa | 29000 ksi |
| Bulk Modulus (Typical for steel) | 140 GPa | 20300 ksi |
| Poissons Ratio (Typical For Steel) | 0.290 | 0.290 |
| Shear Modulus (Typical for steel) | 80 GPa | 11600 ksi |
AISI 1045 is widely used for all industrial applications requiring more wear-resistance and strength. Typical applications of AISI 1045 are as follows:
| Gears | Pins | Rams |
| Shafts | Rolls | Sockets |
| Axles | Spindles | Worms |
| Bolts | Ratchets | Light gears |
| Studs | Crankshafts | Guide rods |
| Connecting rods | Torsion bars | Hydraulic clamps |
Q1: What's your terms of payment?
A: 30%T/T as the upfront deposit, 70% before delivery, We will show you the photos and package before you pay the balance.
Q2: What's the terms of delivery?
A: EXW, FOB, CFR, CIF
Q3: What's the terms of packing?
A: Generally,we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers' requirement.
Q4: What's your delivery time?
A: For stocks, we could transport the goods to loading port within 7 work days after we received the deposit.For productionperiod, it usually takes about 15 days to 30 days after we received the deposit.
Q5: Could you produce according to the samples?
A: Yes, we can customer-made by your samples or technique drawings, we can build the mold and fixtures.
Q6: Could youprovide the compliment samples?
A: Yes, we could provide the free samples on condition that it is available in stocks, however,the transportation fee is borne by buyer.
Q7: How could you guarantee your products quality?
A: Each piece of products is manufactured by certified workshops, inspected by us piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
Q8:What are the advantages of your company?
A:(1): Prime quality and reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Trial order can be done in one week.
(6): Samples can be provided as your requirements
