제품 상세 정보:
|
| 강철 등급: | 합금 강철 | 합금 여부: | 합금입니다 |
|---|---|---|---|
| 기술: | 뜨겁게 굴려지고 추운 채 끌어내집니다 | 애플리케이션: | 공구강 철근 |
| 유형: | 50CrV4 | 기준: | ASTM, DIN |
| 특별 사용: | 곰팡이 스틸 | 모양: | 둥근 |
| 길이: | 1m-6m | 표면: | 검거나 밝습니다 |
| 제품 이름: | 42crmo4 qt 합금강 환봉 | 지름: | 12mm-650mm |
| 배달 조건: | 반열된, 보증금을 받은 후 15일 이내에 | 치수: | 5-900MM |
| 열처리: | 완화시킨 정상화된 +Annealed +Quenched + | ||
| 강조하다: | 51CrV4 alloy steel round bar,50CrVA spring steel rod,ASTM AISI SAE 6150 steel bar |
||
Alloy steels are designated by AISI four-digit numbers. They are more responsive to mechanical and heat treatments than carbon steels. They comprise different types of steels with compositions which exceed the limitations of B, C, Mn, Mo, Ni, Si, Cr, and Va in the carbon steels.
| Technical parameters | |
| Material | 51CrV4 steel round bar |
| Size | Diameter:5mm-1000mm |
| Length:3000mm-6000mm | |
| Origin place | Made In China |
| Delivery Condition | Hot rolled,cold drawn,forged |
| Surface require | Black,grinding,bright,polish,turn,peel |
| Heat treatment | Quenched,Tempered,annealed |
| Packing | seaworthy packing,wooden case,carton,woven bag or at client's requires |
| Delivery time | In 10-50 days |
| Trade Term | EXW,FOB,CIF |
| Payments | T/T or L/C at sight |
| Port | China main Port,such as shanghai, Dalian, shenzhen port. |
| AISI | GB/T | DIN | DIN | C | Si | Mn | P | S | Ni | Cr | Mo | V |
| 4118 | 20CrMo | 18CrMo4 | 1.7243 | 0.18-0.23 | 0.15-0.35 | 0.70-0.90 | ≤ 0.035 | ≤ 0.035 | - | 0.4-0.6 | 0.08-0.15 | - |
| 4130 | 30CrMo | 25CrMo4 | 1.7218 | 0.28-0.33 | 0.15-0.35 | 0.40-0.60 | ≤0.035 | ≤ 0.040 | - | 0.80-1.10 | 0.15-0.25 | - |
| 4135 | 35CrMo | 34CRMO4 | 1.722 | 0.33-0.38 | 0.15-0.35 | 0.70-0.90 | ≤ 0.035 | ≤ 0.040 | - | 0.80-1.10 | 0.15-0.25 | - |
| 4140 | 42CrMo | 42CrMo4 | 1.7225 | 0.38-0.43 | 0.15-0.35 | 0.75-1.00 | ≤ 0.035 | ≤ 0.040 | - | 0.80-1.10 | 0.15-0.25 | - |
| 4340 | 40CrNiMo | 36CrNiMo4 | 1.6563 | 0.38-0.43 | 0.15-0.35 | 0.60-0.80 | ≤ 0.035 | ≤ 0.040 | 1.65-2.00 | 0.70-0.90 | 0.20-0.30 | - |
| 5115 | 15CrMn | 16MnCr5 | 1.7131 | 0.14-0.19 | ≤ 0.4 | 1.0-1.30 | ≤ 0.025 | ≤ 0.035 | - | 0.80-1.10 | - | - |
| 5120 | 20Cr | 20Cr4 | 1.7016 | 0.17-0.22 | 0.15-0.35 | 0.7-0.9 | ≤0.035 | ≤ 0.040 | - | 0.70-0.90 | - | - |
| 5120 | 20CrMn | 20MnCr5 | 1.7147 | 0.17-0.22 | 0.15-0.40 | 1.1-1.4 | ≤ 0.025 | ≤ 0.035 | - | 1.0-1.3 | - | - |
| 5140 | 40Cr | 41Cr4 | 1.7035 | 0.38-0.43 | 0.15-0.35 | 0.7-0.9 | ≤ 0.035 | ≤ 0.040 | - | 0.70-0.90 | - | - |
| 6150 | 50CrV | 51CrV4 | 1.8159 | 0.48-0.53 | 0.15-0.35 | 0.70-0.90 | ≤ 0.035 | ≤ 0.040 | - | 0.80-1.10 | - | ≥0.15 |
| 8620 | 20CrNiMo | 21NiCrMo2 | 1.6523 | 0.18-0.23 | 0.15-0.35 | 0.7-0.9 | ≤ 0.035 | ≤ 0.040 | 0.4-0.7 | 0.4-0.6 | 0.15-0.25 | - |
We Have State Of The Art Production Lines With Leading Edge Technology For Bearing Steel 100Cr6, Stainless Steel 304 / 316 / Duplex UNS S31803 And Super Duplex UNS S3276, Alloy Steel 4130/4140/8620, High Speed Tool T1/M2/M35/M42 And Die Steel D2/D3/H13/H21/P20. The Products Covers Special Steel Round, Square, Flat, Wire Rod, Wire, Sheet, Pipe, Strip And Heavy Forgings. Produces Forged Round Steel (¢120~850mm) And Square Steel (120~550mm) Of Various Steel Grades.
|
Alloy Steel
|
4140,4142,42CrMo4,1.7225,SCM440,4130,SCM430,25CrMo4,1.7218,34CrNiMo6,
1.6582,4340,SNCM439,36CrNiMo4,1.6511,SACN645,1340,SMn438,SNC236 |
|||
|
Tool Steel
|
H13,1.2344,SKD61,D2,SKD11,1.2379,1.2510,01,SKS3,95MnWCr5,D3,SKD1,1.2419,
SKS31,H21,SKD5,1.2581,P20,35CrMo7,1.2738,1.2316,M2 |
|||
|
Bearing Steel
|
GCr15,52100,SUJ1,SUJ2,100Cr6,1.2067,55C,8620,4320,9310,440C,M50
|
|||
|
Spring Steel
|
9260,SUP6,SUP7,1.7108,54SiCr6,1.7102,5155,SUP9,1.7176,5160,1.7177,6150,
SUP10,51CrV4,1.8159 |
|||
|
Stainless Steel
|
321,sus321,1.4541,304,SUS304,1.4301,410,SUS410,1.4006,420,1.4021,1.4028,
434,1.4113,316L,SUS316L,1.4435,630,1.4542,431,1.4057 |
|||
